Buick Regal VI (2017-2020) obj sens ctrl wiring diagram
This page shows the only wiring diagram for the component.obj sens ctrl, which is found in the car Buick Regal VI (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
obj sens ctrl wiring diagram (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BRN/WHT WIRE
CENTER CONSOLE MULTI-FUNCTION SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
FRT PRK LH CRNR SENS
FRT PRK LH MID SENS
FRT PRK LH/RH/MID SENS
FRT PRK RH CRNR SENS
FRT PRK RH MID SENS
FRT PRK SENS LO REF
FUSE 40
GRN WIRE
GRN/BRN WIRE
GRY/GRN WIRE
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT MIDDLE PARKING ASSIST SENSOR
LEFT FRONT OUTER PARKING ASSIST SENSOR
LEFT REAR MIDDLE PARKING ASSIST SENSOR
LEFT REAR OUTER PARKING ASSIST SENSOR
LO SPD GMLAN SER DATA
LO SPD GMLAN SER DATA 2
LOGIC
LR CRNR OBJ SENS SIG
LR MID OBJ SENS SIG
OBJ SENS CTRL
OBJ SENS LO REF
PARKING ASSIST CONTROL MODULE
PARKING ASSIST DISABLE IND
PARKING ASSIST DISABLE SWITCH
RED/GRN WIRE
RIGHT FRONT MIDDLE PARKING ASSIST SENSOR
RIGHT FRONT OUTER PARKING ASSIST SENSOR
RIGHT REAR MIDDLE PARKING ASSIST SENSOR
RIGHT REAR OUTER PARKING ASSIST SENSOR
RR CRNR OBJ SENS SIG
RR MID OBJ SENS SIG
RR PARK ASSIST LED DISABLE SIG
RR PRK ASSIST DISABLE SIG
SIG GND
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit -> OBJ SENS CTRL
