Buick Regal V (2009-2013) srl data wiring diagram
This page shows the only wiring diagram for the component.srl data, which is found in the car Buick Regal V (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
srl data wiring diagram (1 of 1)
3 2 1 IMMOBILIZER SPLY VOLT LINEAR INTERCONNECT
BATT POSITIVE VOLT
BLK WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRN/DK GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER (DIC) DISPLAY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE
GMLAN SERIAL DATA
GRN WIRE
GRY WIRE
HOOD AJAR SW SIG
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH)
HS GMLAN -
IMMOBILIZER CONTROL MODULE (STEERING COLUMN BEHIND STEERING WHEEL)
IMMOBIZER SPLY VOLT
INSTRUMENT CLUSTER
LINEAR INTERCONNECT
LO SPD SERIAL DATA
LOGIC
LOW REFERENCE
LT GRN/WHT WIRE
NETWORK 11
NETWORK 11 LOW REFERENCE
RED/YEL WIRE
SECURITY INDICATOR
SRL DATA
TAN WIRE
WHT/BLK WIRE
Go to component -> Pass-key circuit -> SRL DATA
