Buick Regal V (2009-2013) serial data - computer data lines system wiring diagram
This page shows the only wiring diagram for the component.serial data - computer data lines system, which is found in the car Buick Regal V (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
serial data - computer data lines system wiring diagram (1 of 1)
ACTR LCK CTRL 2
ACTR UNLCK CTRL
AJAR SW SIG 1
BATT POS VOLT (OR 1040)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER INFORMATION CENTER DISPLAY
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FUEL DOOR LOCK ACTUATOR (RIGHT REAR WHEEL WELL NEAR FUEL DOOR)
FUSE 14
FUSE 3 LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HANDLE SW OPEN SIG
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LOWER
LOGIC
MTR RELEASE CTRL
NCA WIRE
REAR COMPARTMENT LID UNLATCH RELAY
SERIAL DATA
SERIAL DATA - COMPUTER DATA LINES SYSTEM
UNDER FRONT OF BATTERY TRAY)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VIO/GRY WIRE
WHT WIRE
YEL/BLU WIRE
Go to component -> Trunk & fuel door release circuit, canada made -> SERIAL DATA - COMPUTER DATA LINES SYSTEM
