Courtesy lamps circuit for Buick Regal III (1988-1997)

1995 VFTC B/H CONN BLK WIRE CHIME MODULE (BELOW LEFT SIDE OF I/P) CTSY LPS ON DOOR AJAR DIMMER SWITCH DK BLU WIRE DOME OFF HI LO FUSE 28 FUSE 39 FUSE BLOCK HD LPS MAXI CIRCUIT BREAKER HEADLIGHT SWITCH HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P COMPARTMENT COURTESY LIGHT I/P COMPARTMENT LIGHT SWITCH IGN INTERIOR LIGHTS LEFT DOOR CYLINDER LIGHT (OLDSMOBILE, BUICK 2 DOOR ONLY) LEFT DOOR HANDLE SWITCH (BUICK, OLDSMOBILE ONLY) LEFT FRONT DOOR COURTESY/ WARNING LIGHT (PONTIAC ONLY) LEFT FRONT DOOR JAMB SWITCH LEFT I/P COURTESY LIGHT LEFT REAR DOOR COURTESY/ WARNING LIGHT LEFT REAR DOOR JAMB SWITCH LEFT SUNSHADE ILLUMINATED MIRROR ORG/ WIRE PNK WIRE PPL REAR COMPARTMENT LID REAR COMPT COURTEST LIGHT RED WIRE REMOTE CONTROL DOOR LOCK RECEIVER (BASE OF RIGHT A PILLAR) RIGHT DOOR HANDLE SWITCH (BUICK, OLDSMOBILE ONLY) RIGHT FRONT DOOR COURTESY/ WARNING LIGHT RIGHT FRONT DOOR JAMB SWITCH RIGHT I/P COURTESY LIGHT RIGHT REAR DOOR COURTESY/ WARNING LIGHT RIGHT REAR DOOR JAMB SWITCH RIGHT SUNSHADE ILLUMINATED MIRROR UNDERHOOD ELECTRICAL CENTER #2 W/ KEYLESS ENTRY WHT WIRE

1995 VFTC B/H CONN BLK WIRE DOME LIGHT DOME/ READING LIGHT FROM FUSE 28 FROM HEADLIGHT SWITCH HOT AT ALL TIMES INSIDE REARVIEW MIRROR LEFT QUARTER COURTESY LIGHT LEFT QUARTER COURTESY LIGHT (BUICK) QUARTER ARMREST COURTESY LIGHT (OLDS) LEFT QUARTER COURTESY/ READING LIGHT ORG/ WIRE REGAL AND GRAND PRIX REGAL, CUTLASS SUPREME AND GRAND PRIX REGAL, CUTLASS SUPREME, GRAND PRIX 4 DOOR AND CUTLASS SUPREME CONVERTIBLE RIGHT QUARTER COURTESY LIGHT RIGHT QUARTER COURTESY LIGHT (BUICK) QUARTER ARMREST COURTESY LIGHT (OLDS) RIGHT QUARTER COURTESY/ READING LIGHT UNDERHOOD ELECTRICAL CENTER #2 HORN FUSE UNDERHOOD LIGHT WHT WIRE WINDSHIELD HEADER COURTESY/ READING LAMP
