Buick Regal III (1988-1997) windshield header courtesy/ reading lamp Wiring diagram
This page shows the only wiring diagram for the component.windshield header courtesy/ reading lamp, which is found in the car Buick Regal III (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield header courtesy/ reading lamp (1 of 1)
1995 VFTC
B/H CONN
BLK WIRE
DOME LIGHT
DOME/ READING LIGHT
FROM FUSE 28
FROM HEADLIGHT SWITCH
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
LEFT QUARTER COURTESY LIGHT
LEFT QUARTER COURTESY LIGHT (BUICK) QUARTER ARMREST COURTESY LIGHT (OLDS)
LEFT QUARTER COURTESY/ READING LIGHT
ORG/ WIRE
REGAL AND GRAND PRIX
REGAL, CUTLASS SUPREME AND GRAND PRIX
REGAL, CUTLASS SUPREME, GRAND PRIX 4 DOOR AND CUTLASS SUPREME CONVERTIBLE
RIGHT QUARTER COURTESY LIGHT
RIGHT QUARTER COURTESY LIGHT (BUICK) QUARTER ARMREST COURTESY LIGHT (OLDS)
RIGHT QUARTER COURTESY/ READING LIGHT
UNDERHOOD ELECTRICAL CENTER #2 HORN FUSE
UNDERHOOD LIGHT
WHT WIRE
WINDSHIELD HEADER COURTESY/ READING LAMP
Go to component -> Courtesy lamps circuit (2 of 2) -> WINDSHIELD HEADER COURTESY/ READING LAMP
