Buick Regal III (1988-1997) transaxle sol b ctrl transaxle sol a ctrl Wiring diagram

413 412 PPL BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DK BLU WIRE DK GRN/WHT WIRE ECM BAT FUSE ENG EMIS FUSE ENGINE COOLANT TEMP SENSOR (TOP LEFT SIDE OF ENGINE) EVAPORATIVE EMISSIONS CANISTER PURGE SOLENOID (TOP OF ENGINE ON INTAKE PLENUM) FUEL PUMP PRIME CONNECTOR FUEL PUMP RELAY (RIGHT SIDE OF ENGINE COMPT, FORWARD OF STRUT TOWER) FUEL PUMP/ OIL PRESSURE SENSOR SWITCH (RIGHT FRONT OF ENGINE NEAR OIL FILTER) FUEL TANK UNIT (TOP OF FUEL TANK) FUSE 39 FUSE BLOCK GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN, BULB TEST OR START INDICATOR INSTRUMENT CLUSTER "SERVICE ENGINE SOON" INTAKE AIR TEMP INPUT INTAKE AIR TEMP SENSOR (LEFT FRONT OF ENGINE COMPARTMENT) KNOCK SENSOR (REAR RIGHT SIDE OF ENGINE) LT BLU/BLK WIRE LT GRN WIRE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (LEFT REAR OF ENGINE, RIGHT TOP OF TRANSAXLE) PNK WIRE PPL PPL 1669 1668 PPL/WHT WIRE RED WIRE RED/BLK WIRE TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCC BRAKE SWITCH INPUT TCC SOL. CTRL TCC/BRAKE SWITCH (BRAKE PEDAL SUPPORT) THROTTLE POSITION SENSOR (MOUNTED TO SFI UNIT) TRANS RANGE PARITY INPUT TRANS RANGE INPUT C TRANSAXLE SOL B CTRL TRANSAXLE SOL A CTRL TRANSMISSION TEMP SENSOR (AUTOMATIC TRANSAXLE) UNDERHOOD ELECTRICAL CENTER 1 WHT WIRE YEL WIRE YEL/BLK WIRE
