Buick Regal III (1988-1997) passengers heater and a/c selector switch Wiring diagram
This page shows the only wiring diagram for the component.passengers heater and a/c selector switch, which is found in the car Buick Regal III (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passengers heater and a/c selector switch (1 of 1)
1995 VFTC
ASHTRAY LIGHT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CHIME MODULE (LEFT SIDE OF I/P)
FOG LIGHT SWITCH
GRY WIRE
GRY/BLK WIRE
HEAD OFF PARK
HEAD-UP DISPLAY (TOP LEFT SIDE OF I/P) (OLDSMOBILE ONLY)
HEADLIGHT SWITCH
HEATER AND A/C CONTROL
HOT AT ALL TIMES PARK LPS FUSE
HUD DIMMER SWITCH
I/P DIMMER SWITCH
INSTRUMENT CLUSTER
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT WINDOW SWITCH
OLDSMOBILE ONLY
ORG/ WIRE
PASSENGERS HEATER AND A/C SELECTOR SWITCH
PONTIAC ONLY
PPL/WHT WIRE
RADIO
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT WINDOW SWITCH
SIR COIL
STEERING WHEEL CONTROLS
TRIP COMPUTER
TRIP COMPUTER (PONTIAC ONLY)
UNDERHOOD ELECTRICAL CENTER #2
WHT WIRE
Go to component -> Instrument illumination circuit -> PASSENGERS HEATER AND A/C SELECTOR SWITCH
