Buick Regal III (1988-1997) park lps fuse fog lps fuse wiring diagram

1995 VFTC ABS MAXI- FUSE ABS RELAY ACCY ACCY BULB TEST LOCK OFF B/H CONN B/H CONN PIN BATTERY BLK WIRE BLU WIRE BRN WIRE BULB TEST ELECTRONIC BRAKE CONTROL MODULE (EBCM) FAN CONT #2 RELAY FAN CONT #1 RELAY FOG LIGHTS RELAY FROM FUSIBLE LINK GENERATOR HD LPS MAXI CIRCUIT BREAKER HEADLIGHT SWITCH HORN FUSE HORN RELAY IGNITION SWITCH LOCK OFF MAXI FUSE MAXI FUSE 1 MAXI FUSE 4 MAXI- FUSE #2 MAXI- FUSE #3 NCA WIRE ORG/ WIRE PARK LPS FUSE FOG LPS FUSE PARK/NEUTRAL POSITION SWITCH (3 SPEED) TRANSAXLE RANGE SWITCH (4 SPEED) PNK WIRE POWER STEERING SOLENOID ACTUATOR POWERTRAIN CONTROL MODULE (PCM) PPL PPL TO FUSE 15 (FUSE BLOCK) R/CMPT REL FUSE ECM BAT FUSE RED WIRE REMOTE BATTERY STUD RUN WIRE RUST FUSIBLE LINK (20 GA) STARTER ASSEMBLY THEFT DETERRENT RELAY TO ECM IGN FUSE (UNDERHOOD ELECTRICAL CENTER #1) TO ENG EMS FUSE (UNDERHOOD ELECTRICAL CENTER #1) PPL TO FUSE 11 (FUSE BLOCK) TO FUSE 16 (FUSE BLOCK) TO FUSE 19 (FUSE BLOCK) TO FUSE 21 (FUSE BLOCK) TO FUSE 23 (FUSE BLOCK) TO FUSE 29 (FUSE BLOCK) TO FUSE 33 (FUSE BLOCK) TO POWER WINDOW CIRCUIT BREAKER C (FUSE BLOCK) PPL TO UNDERHOOD ELECTRICAL CENTER #1 UNDERHOOD ELECTRICAL CENTER #1 (RIGHT SIDE OF ENGINE COMPARTMENT) UNDERHOOD ELECTRICAL CENTER #2 (LEFT SIDE OF ENGINE COMPARTMENT) UNDERHOOD LIGHT (EX LUMINA/ MONTE CARLO) VAR P/S FUSE VIN L, X VIN M VIN X VIN M W/ VARIABLE EFFORT STEERING WHT WIRE YEL WIRE
