Buick Regal III (1988-1997) outside remote control rearview mirror switch left door lock cylinder Wiring diagram
This page shows the only wiring diagram for the component.outside remote control rearview mirror switch left door lock cylinder, which is found in the car Buick Regal III (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside remote control rearview mirror switch left door lock cylinder (1 of 1)
1995 VFTC
2 DOOR W/ SUNROOF
AUXILIARY POWER OUTLET
B/H CONN
B/H CONN CIGAR LIGHTER
BLK WIRE
CHIME MODULE ELECTRONIC BRAKE CONTROL MODULE (EBCM)
CIGAR LIGHTER
CONVERTIBLE AND 4 DOOR W/ SUNROOF W/O SUNROOF
CONVERTIBLE TOP DOWN SWITCH
CUTLASS SUPREME
DOME LIGHT
DOME/ READING LIGHT
ELECTRONIC BRAKE CONTROL MODULE (EBCM) CHIME MODULE
FROM MAXIFUSE #1 (UNDERHOOD ELECTRICAL CENTER #1)
FUSE 1
FUSE 10
FUSE 19
FUSE 28
FUSE 37
FUSE 37 FUSE 19
FUSE BLOCK (RIGHT SIDE OF I/P)
HEATER AND A/C CONTROL
I/P COMPARTMENT LIGHT
I/S REARVIEW MIRROR
INSIDE REARVIEW MIRROR
LEFT DOOR LOCK SWITCH
LEFT I/P COURTESY LIGHT
LEFT QUARTER COURTESY LIGHT
LEFT REAR COURTESY/ READING LIGHT
LEFT SUNSHADE ILLUMINATED MIRROR
LUMINA/MONTE CARLO
NOT USED (4 DOOR ONLY)
ORG/ WIRE
OUTSIDE REMOTE CONTROL REARVIEW MIRROR SWITCH LEFT DOOR LOCK CYLINDER
POWER ANTENNA
RADIO RADIO AMPLIFIER
REAR COMPARTMENT COURTESY LIGHT
REAR COMPT COURTESY LIGHT
RED WIRE
RIGHT DOOR LOCK SWITCH
RIGHT I/P COURTESY LIGHT
RIGHT QUARTER COURTESY LIGHT
RIGHT REAR COURTESY/ READING LIGHT
RIGHT SUNSHADE ILLUMINATED MIRROR
THEFT DETERRENT MODULE
THEFT DETERRENT MODULE RADIO
Go to component -> Power distribution circuit (4 of 6) -> OUTSIDE REMOTE CONTROL REARVIEW MIRROR SWITCH LEFT DOOR LOCK CYLINDER
