Buick Regal III (1988-1997) high beam input Wiring diagram
This page shows the only wiring diagram for the component.high beam input, which is found in the car Buick Regal III (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high beam input (1 of 1)
1995 VFTC
AMBIENT LIGHT SENSOR (TOP RIGHT SIDE OF I/P)
B/H CONN
BLK WIRE
BRN WIRE
DAYTIME RUNNING LIGHTS DIODE (BEHIND LEFT SIDE OF I/P)
DK BLU WIRE
DK GRN WIRE
FUSE 15
FUSE 39
HD LPS MAXI CIRCUIT BREAKER
HEAD OFF PK
HEADLIGHT DIMMER SWITCH
HEADLIGHT SWITCH
HI BEAM
HIGH BEAM IND
HIGH BEAM INPUT
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START FUSE BLOCK
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT HEADLIGHTS
LO BEAM
LO BEAM HI BEAM
LO HI
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
OFF HEAD PK
ORG/ WIRE
PARK BRAKE SWITCH (LOWER LEFT A PILLAR)
PARK LPS FUSE
PNK IGN INPUT LIGHT SENSOR INPUT SENSOR GROUND PARK BRAKE INPUT GROUND WIRE
PNK WIRE
RED WIRE
RIGHT HEADLIGHTS
TAN WIRE
TAN/WHT WIRE
UNDERHOOD ELECTRICAL CENTER #2
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlight circuit, with drl -> HIGH BEAM INPUT
