Buick Regal III (1988-1997) front height adjuster motor w/ecb Wiring diagram
This page shows the only wiring diagram for the component.front height adjuster motor w/ecb, which is found in the car Buick Regal III (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front height adjuster motor w/ecb (1 of 1)
1995 VFTC
BACK
BACK FWD
BLK WIRE
BLU WIRE
BUICK, OLDSMOBILE PONTIAC
BUICK, OLDSMOBILE, PONTIAC CHEVROLET/ OLDSMOBILE CONVERTIBLE
DK DK LT
DOWN
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
ENTIRE SEAT
FORWARD/ BACK ADJUSTER MOTOR W/ECB
FRONT HEIGHT
FRONT HEIGHT ADJUSTER MOTOR W/ECB
FUSE BLOCK
GRN WIRE
HOT AT ALL TIMES POWER SEATS CIRCUIT BREAKER D
ORG/ WIRE
PASSENGER SEAT ADJUSTER MOTOR ASSEMBLY
PASSENGER SEAT ADJUSTER SWITCH
REAR HEIGHT
REAR HEIGHT ADJUSTER MOTOR W/ECB
TAN WIRE
W/ PASSENGER POWER SEAT
YEL WIRE
Go to component -> Power seat circuits -> FRONT HEIGHT ADJUSTER MOTOR W/ECB
