Buick Regal III (1988-1997) eng ems fuse Wiring diagrams
This page contains all the electrical diagrams for the component. eng ems fuse, in which he is found in the car Buick Regal III (1988-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram eng ems fuse (1 of 2)
1-2 CTRL SOL TCC PWM SOL
2-3 SHIFT SOL 1-2 SHIFT SOL TCC SOL TRANS RANGE "A" TRANS RANGE "B"
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
ECM BATT FUSE
ECM IGN FUSE
ENG EMS FUSE
ENGINE COOLANT TEMPERATURE SENSOR (TOP LEFT SIDE OF ENGINE)
FUSE 39
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START
IGNITION IN BATTERY IN MIL INDICATOR CTRL SERIAL DATA
INSTRUMENT CLUSTER
LT GRN WIRE
MALFUNCTION INDICATOR LAMP
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
PPL
STOPLAMP/TORQUE CONVERTER CLUTCH SWITCH (BEHIND LEFT SIDE OF DASH)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TCC FUSE
TCC SOL 2-3 CTRL SOL
TFT SENSOR
THROTTLE POSITION SENSOR (THROTTLE BODY)
TRANS- AXLE
UNDERHOOD ELECTRICAL CENTER 1
VEHICLE SPEED SENSOR (LOWER RIGHT REAR OF ENGINE COMPT, ON TRANSAXLE)
WHT WIRE
WHT/ BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 3.8l (vin l), transmission circuit -> ENG EMS FUSE
Wiring diagram eng ems fuse (2 of 2)
1995 VFTC
A/C CMPR RELAY (EX VIN M)
A/C CMPR RELAY (VIN M ONLY)
AUTOMATIC TRANSAXLE
BRN WIRE
CAMSHAFT POSITION SENSOR CAMSHAFT POSITION SENSOR
CATALYST MONITOR (VIN L ONLY)
CRANKSHAFT POSITION SENSOR
CRUISE CONTROL MODULE
CRUISE FUSE
DIGITAL EXHAUST GAS RECIRCULATION (DEGR) VALVE (EX VIN L)
ECM IGN FUSE
ELECTRONIC IGNITION CONTROL MODULE
ELEK IGN FUSE
ENG EMS FUSE
EVAPORATIVE EMISSIONS (EVAP) CANISTER PURGE SOLENOID VALVE HEATED OXYGEN SENSOR
EX VIN L
F/INJN FUSE
FAN CONT 2 RELAY
FROM IGNITION SWITCH
FUEL INJECTOR 1
FUEL INJECTOR 2 FUEL INJECTOR 4 FUEL INJECTOR 3
FUEL INJECTOR 5
FUEL INJECTOR 6
GENERATOR POWER STEERING PRESSURE SWITCH (VIN X ONLY)
HIGH RESOLUTION
LINEAR EXHAUST GAS RECIRCULATION (DEGR) VALVE (VIN L ONLY)
MASS AIR FLOW (MAF) SENSOR (EX VIN M)
PNK PNK PNK WIRE
PNK PNK WIRE
PNK VIN X VIN M WIRE
PNK VIN X WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL MODULE (PCM) (VIN L ONLY)
PPL
TCC FUSE
TRANSAXLE RANGE SWITCH
UNDERHOOD ELECTRICAL CENTER #1 (RIGHT SIDE OF ENGINE COMPARTMENT)
VIN L VIN M
VIN M VIN X
VIN X ONLY
VIN X VIN M
Go to component -> Power distribution circuit (6 of 6) -> ENG EMS FUSE
