Buick Regal III (1988-1997) 1829 1829 pnk pnk key res in key res in Wiring diagram
This page shows the only wiring diagram for the component.1829 1829 pnk pnk key res in key res in, which is found in the car Buick Regal III (1988-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1829 1829 pnk pnk key res in key res in (1 of 1)
1829 1829 PNK PNK KEY RES IN KEY RES IN WIRE
1995 VFTC
ACCY
BAT IGN ENABLE OUT RLY CNTRL IND CNTRL PNK WIRE
BLK WIRE
BULB TEST
DATA LINK CONNECTOR (BOTTOM OF I/P, RIGHT OF STEERING COLUMN)
DK BLU WIRE
FUEL ENABLE
FUSE 10
FUSE 12
FUSE BLOCK (RIGHT SIDE OF I/P)
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
IGNITION SWITCH
LOCK OFF
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT)
PPL
RUN WIRE
STARTER SOLENOID
STARTING/ CHARGING SYSTEM
THEFT DETERRENT MODULE (BEHIND RIGHT SIDE OF I/P)
THEFT DETERRENT RELAY (BEHIND RIGHT SIDE OF I/P)
YEL WIRE
YEL/BLK WIRE
Go to component -> Pass-key circuit, with seo -> 1829 1829 PNK PNK KEY RES IN KEY RES IN WIRE
