Buick LeSabre VIII (2000-2005) w/2 way power seats Wiring diagram
This page shows the only wiring diagram for the component.w/2 way power seats, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/2 way power seats (1 of 1)
6 WAY SEATS 8 WAY SEATS
BATTERY
BLK WIRE
COAX
DASH INTEGRATION MODULE (DIM)
DRIVER HEATED SEAT MODULE
DRIVER MEMORY SEAT MODULE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT RECLINE SWITCH
FLOOR CTSY LMP RELAY
FRONT AUXILIARY POWER OUTLET
FRONT PASSENGER HEATED SEAT MODULE
FRONT PASSENGER SEAT ADJUSTER SWITCH
FRONT PASSENGER SEAT RECLINE SWITCH
FUEL DOOR LOCK RELAY FUEL DOOR UNLOCK RELAY
IGN-1 RELAY FUEL PUMP RELAY
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
LEFT REAR DOOR MODULE (LRDM)
NCA WIRE
ONSTAR CELLULAR ANTENNA
REAR AUXILIARY POWER OUTLET
REAR WINDOW DEFOGGER
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT REAR DOOR MODULE (RRDM)
SPLICE PACK
VEHICLE COMMUNICATION UNIT (VCU)
W/2 WAY POWER SEATS
W/6, 8 WAY POWER SEATS
W/HEATED SEATS
W/MEMORY, LUMBAR SEATS, AUTO DIMMING INSIDE REAR VIEW, OUTSIDE MIRRORS
W/O HEATED SEATS
W/O HEATED SEATS W/HEATED SEATS
W/O MEMORY, LUMBAR SEATS, AUTO DIMMING INSIDE REAR VIEW, OUTSIDE MIRRORS
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> W/2 WAY POWER SEATS
