Buick LeSabre VIII (2000-2005) simple bus interface (sbi) class 2 serial data line wiring diagram
This page shows the only wiring diagram for the component.simple bus interface (sbi) class 2 serial data line, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
simple bus interface (sbi) class 2 serial data line wiring diagram (1 of 1)
AIR TEMPERATURE SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
CLASS 2 SERIAL DATA LINE
CLASS 2 SERIAL DATA LINE INTERIOR LAMP SWITCH INPUT
COMPUTER DATA LINES SYSTEM
DASH INTEGRATION MODULE (DIM) (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR)
DRIVER DOOR LOCK SWITCH MEMORY FUNCTION SWITCH (IF EQUIPPED)
DRIVER WINDOW SWITCH DRIVER HEATED SEAT SWITCH (IF EQUIPPED)
DRIVERS DOOR MODULE (UPPER RIGHT CORNER OF DOOR, BEHIND TRIM PANEL)
FRONT PASSENGER POWER DOOR LOCK SWITCH
FRONT PASSENGER POWER WINDOW SWITCH
GRN WIRE
GROUND
HEADLAMP SWITCH
I/P DIMMER SWITCH
I/P DIMMER SWITCH INPUT
INCADESCENT DIMMING OUTPUT
INSTRUMENT CLUSTER (IPC)
INTERIOR LAMP SWITCH
OFF
PNK/BLK WIRE
PPL
RADIO
REAR INTEGRATION MODULE (RIM) (BEHIND UPPER LEFT REAR SEAT CUSHION)
REF
RIGHT FRONT DOOR MODULE (RFDM) SIMPLE BUS INTERFACE (SBI)
RIGHT FRONT HEATED SEAT SWITCH (IF EQUIPPED)
SENSOR RETURN
SIMPLE BUS INTERFACE (SBI) CLASS 2 SERIAL DATA LINE
TAN WIRE
TWILIGHT DELAY SWITCH
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> SIMPLE BUS INTERFACE (SBI) CLASS 2 SERIAL DATA LINE
