Buick LeSabre VIII (2000-2005) rap fuse Wiring diagrams
This page contains all the electrical diagrams for the component. rap fuse, in which he is found in the car Buick LeSabre VIII (2000-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rap fuse (1 of 2)
ALDL FUSE
AUDIO FUSE
BLK WIRE
BODY FUSE
BRN WIRE
BRN/WHT WIRE
CIGAR FUSE
CIGAR RELAY
DATA LINK CONNECTOR
DIMR FUSE
DK BLU WIRE
DK GRN WIRE
DRIVER MEMORY SEAT MODULE
DRIVER SEAT ADJUSTER SWITCH DASH INTEGRATION MODULE
DRIVER SEAT LUMBAR SWITCH
F/ PMP RELAY
F/PMP FUSE
F/TNK DR LOCK RELAY
F/TNK DR REL RELAY
FROM ALDL FUSE (DIAGRAM 2 OF 4)
FROM AUX/PWR FUSE (DIAGRAM 1 OF 4)
FROM BATTERY (DIAGRAM 1 OF 4)
FROM CIGAR FUSE (DIAGRAM 2 OF 4)
GARAGE DOOR OPENER
GENERATOR
HTDST LF FUSE DIM FUSE
HTDST RF FUSE
HVAC BATT FUSE
HVAC CONTROL MODULE
IGN 1 RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL INTEGRATION MODULE
INT LAMP RELAY
INT LP FUSE
LEFT FRONT TURN SIGNAL/ PARK LAMP RIGHT FRONT TURN SIGNAL/ PARK LAMP
LEFT LICENSE PLATE LAMP
LEFT MARKER LAMP LEFT TAIL/ STOP LAMP
LEFT TAIL/ STOP LAMP
LP PKL FUSE
LP PKR FUSE
MEM FUSE
NCA WIRE
ORG/ WIRE
PARK LP RELAY
PARK RELAY
PNK (IN BODY HARN, 17 CM WIRE
PNK PNK WIRE
PNK WIRE
POWER SUN ROOF MODULE
PPL
PPL PPL
PRK/REV FUSE
RADIO
RAP FUSE
RAP RELAY
REAR DEFOG RELAY
REAR FUSE BLOCK
REAR INTEGRATION MODULE
REAR INTRGRATION MODULE
REVERSE RELAY
RIGHT LICENSE PLATE LAMP DASH INTEGRATION MODULE
RIGHT TAIL/ STOP LAMP
RIGHT TAIL/ STOP LAMP RIGHT MARKER LAMP
RR DEFOG FUSE
STOPLIGHT/ AUTO TRANS SHIFT LOCK CONTROL SWITCH
TO DRV MDL FUSE (DIAGRAM 3 OF 4)
TO IGN-1 RELAY (DIAGRAM 2 OF 4)
TO PARK LP RELAY (DIAGRAM 2 OF 4)
TO REAR FUSE BLOCK (DIAGRAM 4 OF 4)
TRK REL RELAY
UNDER- HOOD FUSE BLOCK
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
VENT SOL FUSE SIR FUSE IGN-1 FUSE
W/ ELECTRONIC A/C
W/ UNIVERSAL GARAGE DOOR OPENER
W/O ELECTRONIC A/C
W/O UNIVERSAL GARAGE DOOR OPENER
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> RAP FUSE
Wiring diagram rap fuse (2 of 2)
1 2 3 4 5 6 7 8 GROUND
2074 128 EXPRESS INP GROUND SLIDE INPUT VENT INPUT LIMIT SW
B+ MOTOR CTRL MOTOR CTRL GROUND
BLK WIRE
BLU WIRE
BRN WIRE
BUICK PONTIAC
CLOSE
DK BLU WIRE
DK GRN WIRE
EXPRESS OPEN
GRN WIRE
HOT AT ALL TIMES
LIMIT SWITCH
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
RAP CONTROL
RAP FUSE
RAP RELAY
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
REAR INTEGRATION MODULE (BEHIND UPPER LEFT REAR SEAT CUSHION)
RED WIRE
SUN ROOF MODULE (REAR OF GLASS ASSEMBLY, ABOVE HEADLINER)
SUN ROOF MOTOR (REAR OF GLASS ASSEMBLY, ABOVE HEADLINER)
SUN ROOF SWITCH (IN OVERHEAD CONSOLE)
YEL WIRE
Go to component -> Power top/sunroof circuit -> RAP FUSE
