Buick LeSabre VIII (2000-2005) pwr door serial data class 2 serial data b+ class 2 serial data ppl Wiring diagram
This page shows the only wiring diagram for the component.pwr door serial data class 2 serial data b+ class 2 serial data ppl, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr door serial data class 2 serial data b+ class 2 serial data ppl (1 of 1)
1 2 4 8 LF DOOR KEY SW SIG LF DOOR OPEN IN GROUND GROUND
11 15 B+ PWR DOOR SERIAL DATA
2 4 DOOR OPEN INPUT GROUND
B+ PWR DOOR SERIAL DATA GROUND DOOR OPEN INPUT
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASH INTEGRATION MODULE (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR)
DK BLU WIRE
DK GRN WIRE
DOOR OPEN
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MODULE
DRV MDL FUSE 7
FRONT PASSENGER DOOR LOCK ACTUATOR
FRONT PASSENGER DOOR MODULE
HORN CTRL LIGHTS CTRL
HORNS SYSTEM
HOT AT ALL TIMES
KEY CYLINDER DISARM/ UNLOCK
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR DOOR MODULE
LT GRN WIRE
ORG/ WIRE
PASS MDL FUSE 25
PPL
PPL PPL 1807 1807 SERIAL DATA CLASS 2
PWR DOOR SERIAL DATA CLASS 2 SERIAL DATA B+ CLASS 2 SERIAL DATA PPL
REAR FUSE BLOCK
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR DOOR MODULE
RRDR MDL FUSE 18
TAN WIRE
TAN/WHT WIRE
Go to component -> Forced entry circuit -> PWR DOOR SERIAL DATA CLASS 2 SERIAL DATA B+ CLASS 2 SERIAL DATA PPL
