Buick LeSabre VIII (2000-2005) ppl data lines Wiring diagram
This page shows the only wiring diagram for the component.ppl data lines, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl data lines (1 of 1)
BATTERY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM INSTRUMENT CLUSTER SYSTEM
DIMMING
DIMMING SIGNAL
DK BLU WIRE
DK GRN/WHT WIRE
GROUND
HEAD-UP DISPLAY (HUD) DIMMER SWITCH
HEAD-UP DISPLAY (ON TOP LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE
IGN 3 FUSE
IGNITION
IMAGE DOWN
IMAGE UP
INSTRUMENT CLUSTER CIRCUIT
LF TURN SIGNAL
LT BLU WIRE
MOTOR DOWN FEED
MOTOR UP FEED
ORG/ WIRE
PASS THROUGH GROMMET)
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING)
PPL DATA LINES
PPL/WHT WIRE
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
RF TURN SIGNAL
VEHICLE SPEED SIGNAL
YEL WIRE
Go to component -> Head-up display circuit -> PPL DATA LINES
