Buick LeSabre VIII (2000-2005) oxy sen fuse dis fuse Wiring diagram
This page shows the only wiring diagram for the component.oxy sen fuse dis fuse, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oxy sen fuse dis fuse (1 of 1)
1 RELAY
A/C CLU FUSE
ACCY FUSE
ACCY RELAY
AUTOMATIC TRANS- MISSION
AUX PWR FUSE
BATTERY
BLK WIRE
C/LTR FUSE 20
CIGAR LIGHTER
CIRCUIT BREAKER
COOL FAN 1 FUSE
COOL FAN 1 RELAY (LOW SPEED)
COOL FAN 2 FUSE
COOL FAN 2 RELAY (HIGH)
COOL FAN S/P RELAY A/C CLUTCH RELAY
CR CONT FUSE INJR 1 FUSE
DK GRN WIRE
DRL RELAY
FOG/ DRL FUSE
FROM FOG/ DRL FUSE (DIAGRAM 1 OF 4)
FROM PCM BATT FUSE (DIAGRAM 1 OF 4)
FRONT AUXILIARY POWER OUTLET REAR AUXILIARY POWER OUTLET
FUEL INJECTOR 3 FUEL INJECTOR 1 FUEL INJECTOR 6
FUEL INJECTOR 4 FUEL INJECTOR 2 CRUISE CONTROL MODULE
FUSIBLE LINK
GENERATOR
HDHI BMR FUSE ABS FUSE
HDHI- BML FUSE
HDLO BML FUSE HDLO BMR FUSE
HDLP HI BM RELAY
HDLP LO BM RELAY
HORN FUSE
HORN RELAY
IGN 1 FUSE
IGN 1 RELAY
INJR 2 FUSE
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP RIGHT LOW BEAM HEADLAMP
LT GRN WIRE
ORG/ WIRE
OUTSIDE MOISTURE SENSOR WIND- SHIELD WIPER SWITCH
OXY SEN FUSE DIS FUSE
PCM BATT FUSE
PCM IGN FUSE
PNK PNK PNK WIRE
PNK WIRE
POWER- TRAIN CONTROL MODULE THEFT DETERRENT CONTROL MODULE
POWERTRAIN CONTROL MODULE
RED WIRE
RIGHT HIGH BEAM HEADLAMP ELECTRONIC BRAKE CONTROL MODULE
SPEED
START 1 RELAY
STARTER SOLENOID
TAN WIRE
TO BODY FUSE (DIAGRAM 2 OF 4)
TO CIGAR RELAY (DIAGRAM 2 OF 4)
TO HDLP LO BM RELAY (DIAGRAM 1 OF 4)
TO IGN 1 RELAY (DIAGRAM 1 OF 4)
TO UNDERHOOD FUSE BLOCK (DIAGRAM 4 OF 4)
TRANS FUSE
UNDERHOOD FUSE BLOCK
W/ BATTERY SAVER
W/O BATTERY SAVER
WHT WIRE
WIND- SHIELD WIPER MOTOR
WSW FUSE
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> OXY SEN FUSE DIS FUSE
