Buick LeSabre VIII (2000-2005) lower rt air temp sen sig Wiring diagram

5 VOLT REF LOW MODE DOOR POS SEN SIG AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM BATTERY POSITIVE VOLTAGE IGNITION 3 VOLTAGE BLK WIRE BLK/WHT WIRE BLOWER SPEED CTRL SIG BRN WIRE DK BLU WIRE DK GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON HVAC BATT FUSE HVAC FUSE I/P LAMPS DIMMER SW SIG 5 VOLT REF IGN-3 RELAY INSTRUMENT PANEL INTEGRATION MODULE (IPM) (BEHIND LEFT SIDE OF DASH) INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM INTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM KEY IN IGNITION SIG TWILIGHT SENTINEL DELAY SIG PPL LOWER RT AIR TEMP SEN SIG LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL REAR FUSE BLOCK (UNDER LEFT REAR SEAT) SPLICE PACK TAN WIRE TRACTION CTRL SW SIG DR HVAC CONTROL ASSBLY SIG DR HVAC CTRL ASSBLY CLK SIG WARNINGS SYSTEM HEADLIGHTS SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
