Buick LeSabre VIII (2000-2005) left high beam head- lamp Wiring diagrams

BLK WIRE BLK/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (DIM) (RIGHT SIDE OF DASH) DIMMER SWITCH DK GRN WIRE DRL RELAY FLASH TO PASS SWITCH FOG/ DRL FUSE GRN WIRE HDHI- BML FUSE HDHI- BMR FUSE HDLO- BML FUSE HDLO- BMR FUSE HDLP HI BM RELAY HDLP LO BM RELAY HEADLAMP BEAM SWITCH HEADLAMP DIMMER SWITCH HEADLAMP SWITCH HI LOW HOT AT ALL TIMES I/P FUSE INSTRUMENT PANEL INTEGRATION MODULE (BEHIND LEFT SIDE OF DASH) INTERIOR LAMP SWITCH LEFT HIGH BEAM HEAD- LAMP LEFT LOW BEAM HEAD- LAMP LIGHTS ON IND LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PK LP SWITCH PNK WIRE PNK/BLK WIRE PNK/WHT WIRE PPL PPL PPL PPL/WHT WIRE PRK LP RELAY REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RIGHT HIGH BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP SPLICE PACK TAN WIRE TWILIGHT DELAY SW UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT) W/ CORNERING LAMPS WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE YEL/BLK WIRE

BLK WIRE BLK/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (DIM) (RIGHT SIDE OF DASH) DIMMER SWITCH DK GRN WIRE DRL RELAY FLASH TO PASS SWITCH FOG/ DRL FUSE GRN WIRE HDHI- BML FUSE HDHI- BMR FUSE HDLO- BML FUSE HDLO- BMR FUSE HDLP HI BM RELAY HDLP LO BM RELAY HEADLAMP BEAM SWITCH HEADLAMP DIMMER SWITCH HEADLAMP SWITCH HI LOW HOT AT ALL TIMES HVAC CONTROL MODULE (BEHIND LEFT SIDE OF DASH) I/P FUSE INTERIOR LAMP SWITCH LEFT HIGH BEAM HEAD- LAMP LEFT LOW BEAM HEAD- LAMP LIGHTS ON IND LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PK LP SWITCH PNK WIRE PNK/BLK WIRE PNK/WHT WIRE PPL PPL PPL PPL/WHT WIRE PRK LP RELAY REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RIGHT HIGH BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP SPLICE PACK TAN WIRE TWILIGHT DELAY SW UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT) W/ CORNERING LAMPS WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE YEL/BLK WIRE
