Buick LeSabre VIII (2000-2005) dim fuse Wiring diagrams

BATTERY BATTERY VOLT INDICATOR BATTERY VOLTS HIGH BATTERY VOLTS LOW BLK WIRE BLK/WHT WIRE CHECK CHARGE SYSTEM DASH INTEGRATION MODULE (DIM) (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR) DIM FUSE DRIVER INFORMATION CENTER GEN FIELD DUTY CYCLE SIG GEN TURN ON SIG GENERATOR B+ GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING) PPL PPL SERIAL DATA CLASS 2 REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RED WIRE SERIAL CLASS 2 DATA STARTER SOLENOID SYSTEM VOLTAGE MEASUREMENT UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)

103 301 1538 HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM WIPER/WASHER SYSTEM 1375 1485 1080 SOUND SYSTEMS HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM 1807 1807 COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 1969 1483 HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM BACKLIGHT LAMPS CONTROL BATTERY BATTERY POSITIVE VOLTAGE IGNITION 3 VOLTAGE BATTERY POSITIVE VOLTAGE IP LAMP FUSE SUP VOLTAGE BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DASH INTEGRATION MODULE (DIM) (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR) DIM FUSE DK BLU WIRE DK GRN WIRE FLASH TO PASS IN GROUND HEADLAMP HI BEAM RLY CTRL CONTROL POWER HEADLAMP ON SIG PARKLAMP SW ON SIG HEADLAMPS/WIPERS SIG HEADLIGHTS SYSTEM HORN RLY CTRL HORNS SYSTEM HOT AT ALL TIMES IGN SW FUSE IGNITION SWITCH LOCK UNLOCK LT BLU WIRE LT GRN/BLK WIRE OFF/RUN/CRANK VOLTAGE ACCESSORY VOLTAGE IGNITION POSITIVE VOLTAGE DRL RLY CTRL ORG/ WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PPL REMOTE RADIO CTRL HEAD FLASH TO PASS SW SUP VOLT PARK LAMP RLY CTRL REAR FUSE BLOCK (UNDER LEFT REAR SEAT) RUN WIRE SOUND SYSTEMS SPLICE PACK STEERING WHEEL CTRL SIG UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENG COMPT) WHT WIRE YEL WIRE
