Buick LeSabre VIII (2000-2005) courtesy lamp ground Wiring diagram
This page shows the only wiring diagram for the component.courtesy lamp ground, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram courtesy lamp ground (1 of 1)
BLK WIRE
COURTESY LAMP GROUND
DK BLU WIRE
DK BLU/WHT WIRE
FROM REAR FUSE BLOCK (DIAGRAM 1 OF 2)
FRONT PASSENGER DOOR COURTESY LAMP
FRONT PASSENGER FOOT WELL COURTESY LAMP
GRY WIRE
I/P COMPARTMENT SWITCH/ LAMP
INADVERTENT POWER INPUT
LEFT FRONT READING COURTESY LAMP
LEFT REAR READING COURTESY LAMP
LEFT VANITY MIRROR
OVERHEAD CONSOLE
REAR INTEGRATION MODULE (RIM) (BEHIND UPPER LEFT REAR SEAT CUSHION)
RIGHT FRONT READING COURTESY LAMP
RIGHT REAR DOOR COURTESY LAMP
RIGHT REAR READING COURTESY LAMP
RIGHT VANITY MIRROR
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> COURTESY LAMP GROUND
