Buick LeSabre VIII (2000-2005) cool fan 1 fuse 47 cool fan 2 fuse 46 Wiring diagram
This page shows the only wiring diagram for the component.cool fan 1 fuse 47 cool fan 2 fuse 46, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cool fan 1 fuse 47 cool fan 2 fuse 46 (1 of 1)
BLK WIRE
COOL FAN 1 FUSE 47 COOL FAN 2 FUSE 46
COOLFAN 1 RELAY 40
COOLFAN 2 RELAY 37
COOLFAN S/P RELAY 39
DK BLU WIRE
DK GRN WIRE
ECT SENS SIG
GRY WIRE
HI FAN CTRL
HOT AT ALL TIMES
LEFT COOLING FAN
LOW FAN CTRL
LOW REF
LT BLU WIRE
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING)
RIGHT COOLING FAN
SPLICE PACK
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> COOL FAN 1 FUSE 47 COOL FAN 2 FUSE 46
