Buick LeSabre VIII (2000-2005) class 2 serial data line interior lamp switch input Wiring diagram

AIR TEMPERATURE SWITCH ASSEMBLY BLK WIRE BLU WIRE CLASS 2 SERIAL DATA LINE CLASS 2 SERIAL DATA LINE INTERIOR LAMP SWITCH INPUT COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (DIM) (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR) DRIVER DOOR LOCK SWITCH MEMORY FUNCTION SWITCH (IF EQUIPPED) DRIVER WINDOW SWITCH DRIVER HEATED SEAT SWITCH (IF EQUIPPED) DRIVERS DOOR MODULE (UPPER RIGHT CORNER OF DOOR, BEHIND TRIM PANEL) FRONT PASSENGER POWER DOOR LOCK SWITCH FRONT PASSENGER POWER WINDOW SWITCH GRN WIRE GROUND HEADLAMP SWITCH I/P DIMMER SWITCH I/P DIMMER SWITCH INPUT INCADESCENT DIMMING OUTPUT INSTRUMENT CLUSTER (IPC) INTERIOR LAMP SWITCH OFF PNK/BLK WIRE PPL RADIO REAR INTEGRATION MODULE (RIM) (BEHIND UPPER LEFT REAR SEAT CUSHION) REF RIGHT FRONT DOOR MODULE (RFDM) SIMPLE BUS INTERFACE (SBI) RIGHT FRONT HEATED SEAT SWITCH (IF EQUIPPED) SENSOR RETURN SIMPLE BUS INTERFACE (SBI) CLASS 2 SERIAL DATA LINE TAN WIRE TWILIGHT DELAY SWITCH WHT WIRE YEL WIRE
