Buick LeSabre VIII (2000-2005) 55 72 64 vehicle speed out disable output vss high Wiring diagram
This page shows the only wiring diagram for the component.55 72 64 vehicle speed out disable output vss high, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 55 72 64 vehicle speed out disable output vss high (1 of 1)
55 72 64 VEHICLE SPEED OUT DISABLE OUTPUT VSS HIGH
ABS/TCC SWITCH (NEAR BRAKE PEDAL)
BLK WIRE
CR CONT FUSE
CRUISE CONTROL MODULE (ON LEFT SIDE OF ENGINE COMPT, ON STRUT TOWER)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGAGED INPUT
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON, START
IGN 1 FUSE
INFLATABLE RESTRAINT STEERING WHEELS MODULE COIL
LEFT STEERING WHEELS CONTROLS
LT BLU/BLK WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING)
PPL
PPL PPL
PPL VSS LOW
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
RESUME/ ACCEL
RIGHT STEERING WHEELS CONTROLS
SET/ COAST
SPLICE PACK
STEERING COLUMN FUSE HOLDER
STOP LP FUSE
STOPLAMP SWITCH (ON BRAKE PEDAL BRACKET)
TRANSMISSION SYSTEM
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE)
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> 55 72 64 VEHICLE SPEED OUT DISABLE OUTPUT VSS HIGH
