Buick LeSabre VIII (2000-2005) 5 volt reference a 5 volt reference a 5 volt reference b sensor ground Wiring diagram

5 VOLT REFERENCE A 5 VOLT REFERENCE A 5 VOLT REFERENCE B SENSOR GROUND A/C COMP RELAY CONTROL A/C SYSTEM A/T FLUID TEMP INPUT FUEL LEVEL INPUT ANTI-LOCK BRAKE SYSTEM BLK WIRE BLK/WHT WIRE BOOST CONTROL SOLENOID (VIN 1) BRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENG OIL LEVEL SW INPUT CRUISE STATUS BRAKE PEDAL SW OUT GEN TERM L CONTROL ENGINE COOLANT TEMPERATURE (ECT) SENSOR EVAP SOLENOID CONTROL FUEL PUMP RELAY CONTROL EGR VALVE CONTROL MIL CONTROL EVAPORATIVE EMISSIONS (EVAP) CANISTER VENT VALVE FUEL INJ 3 CONTROL FUEL TANK PRESS SENSOR TRANS RANGE SW C INPUT FUEL TANK SENDER GRY (OR GRY/BLK) WIRE GRY WIRE HEATED OXYGEN BANK 1 SENSOR 1 (IN RIGHT EXHAUST MANIFOLD) HEATED OXYGEN BANK 1 SENSOR 2 (REAR OF CATALYTIC CONVERTER) HOT IN RUN AND START HOT IN RUN, START IAC COIL A HIGH TACH SIGNAL DELIVERED TORQUE CONTROL IAC COIL A LOW PRESS SOL HIGH CONTROL PRESS SOL LOW CONTROL IAC COIL B LOW IAT SENSOR INPUT IDLE AIR CONTROL (IAC) VALVE (ON THROTTLE BODY ASSEMBLY) IGN 1 FUSE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE NCA WIRE OIL PRESSURE SIGNAL OXY SEN FUSE PCM IGN FUSE PNK (OR PNK/BLK) WIRE PNK 1 2 3 4 5 6 7 8 9 10 11 12 WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING) PPL PPL PPL REAR FUSE BLOCK RED WIRE RED/BLK WIRE STARTER RELAY OUTPUT BOOST SOLENOID CONTROL TCC PWM SOL CONTROL 1724 418 STARTING/CHARGING SYSTEM TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TOP OF TRANSMISSION) TRANS RANGE SW A INPUT TRANS TCC RELEASE SW IN UNDER- HOOD FUSE BLOCK VENT SOL FUSE WHT WIRE YEL WIRE YEL/BLK WIRE
