Buick LeSabre VIII (2000-2005) 39 27 35 34 clutch rly ctrl sensor signal low ref Wiring diagram
This page shows the only wiring diagram for the component.39 27 35 34 clutch rly ctrl sensor signal low ref, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 39 27 35 34 clutch rly ctrl sensor signal low ref (1 of 1)
39 27 35 34 CLUTCH RLY CTRL SENSOR SIGNAL LOW REF
A/C CLU FUSE 26
A/C CLU RELAY 32
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH DIODE (NEAR A/C COMPRESSOR)
A/C REFRIGERANT PRESSURE SENSOR (BEHIND A/C COMPRESSOR, ON A/C LINE)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING)
PPL PPL 1807 1807 58 59 CLASS 2 SERIAL CLASS 2 SERIAL
RED/BLK WIRE
SPLICE PACK
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
Go to component -> Compressor circuit -> 39 27 35 34 CLUTCH RLY CTRL SENSOR SIGNAL LOW REF
