Buick LeSabre VIII (2000-2005) 2074 128 express inp ground slide input vent input limit sw Wiring diagram
This page shows the only wiring diagram for the component.2074 128 express inp ground slide input vent input limit sw, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2074 128 express inp ground slide input vent input limit sw (1 of 1)
1 2 3 4 5 6 7 8 GROUND
2074 128 EXPRESS INP GROUND SLIDE INPUT VENT INPUT LIMIT SW
B+ MOTOR CTRL MOTOR CTRL GROUND
BLK WIRE
BLU WIRE
BRN WIRE
BUICK PONTIAC
CLOSE
DK BLU WIRE
DK GRN WIRE
EXPRESS OPEN
GRN WIRE
HOT AT ALL TIMES
LIMIT SWITCH
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
RAP CONTROL
RAP FUSE
RAP RELAY
REAR FUSE BLOCK (UNDER LEFT REAR SEAT)
REAR INTEGRATION MODULE (BEHIND UPPER LEFT REAR SEAT CUSHION)
RED WIRE
SUN ROOF MODULE (REAR OF GLASS ASSEMBLY, ABOVE HEADLINER)
SUN ROOF MOTOR (REAR OF GLASS ASSEMBLY, ABOVE HEADLINER)
SUN ROOF SWITCH (IN OVERHEAD CONSOLE)
YEL WIRE
Go to component -> Power top/sunroof circuit -> 2074 128 EXPRESS INP GROUND SLIDE INPUT VENT INPUT LIMIT SW
