Buick LeSabre VIII (2000-2005) 1807 1807 ppl ppl class 2 serial data class 2 serial data key in signal Wiring diagram

1807 1807 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA 1807 1807 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA KEY IN SIGNAL BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DASH INTEGRATION MODULE (DIM) (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR) DK BLU WIRE DOOR OPEN DRIVER DOOR LOCK ACTUATOR DRIVER'S DOOR MODULE (DDM) GROUND HEADLAMP SWITCH PARK LAMP SWITCH HEATER-A/C CONTROL IGNITION KEY ALARM SWITCH (CLOSED W/KEY IN IGNITION) INSTRUMENT PANEL CLUSTER (IPC) INSTRUMENT PANEL INTEGRATION MODULE (IPM) (BEHIND LEFT SIDE OF DASH) KEY IN IGNITION SW CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA 1807 1807 PPL PPL LEFT FRONT SEAT BELT SWITCH (CLOSED W/SEAT BELT UNBUCKLED) LEFT TURN LEFT TURN RIGHT TURN PARK BRAKE SW SIG LF DOOR OPEN SWITCH SIGNAL LT BLU WIRE LT GRN WIRE NCA WIRE OFF PARK PARK BRAKE SWITCH (CLOSED W/PARK BRAKE APPLIED) PARK LAMP SWITCH ON SIGNAL POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING) PPL PPL CLASS 2 SERIAL DATA PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA RADIO RIGHT TURN TAN WIRE W/AUTOMATIC AIR CONDITIONING W/MANUAL AIR CONDITIONING WHT WIRE
