Buick LeSabre VIII (2000-2005) 1807 1807 ppl ppl class 2 serial data class 2 serial data Wiring diagram
This page shows the only wiring diagram for the component.1807 1807 ppl ppl class 2 serial data class 2 serial data, which is found in the car Buick LeSabre VIII (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1807 1807 ppl ppl class 2 serial data class 2 serial data (1 of 1)
1807 1807 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
1807 1807 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA KEY IN SIGNAL
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DASH INTEGRATION MODULE (DIM) (BEHIND RIGHT SIDE OF DASH, UNDER SOUND INSULATOR)
DK BLU WIRE
DOOR OPEN
DRIVER DOOR LOCK ACTUATOR
DRIVER'S DOOR MODULE (DDM)
GROUND
HEADLAMP SWITCH PARK LAMP SWITCH
HEATER-A/C CONTROL
IGNITION KEY ALARM SWITCH (CLOSED W/KEY IN IGNITION)
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL INTEGRATION MODULE (IPM) (BEHIND LEFT SIDE OF DASH)
KEY IN IGNITION SW CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA 1807 1807 PPL PPL
LEFT FRONT SEAT BELT SWITCH (CLOSED W/SEAT BELT UNBUCKLED)
LEFT TURN
LEFT TURN RIGHT TURN PARK BRAKE SW SIG
LF DOOR OPEN SWITCH SIGNAL
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF PARK
PARK BRAKE SWITCH (CLOSED W/PARK BRAKE APPLIED)
PARK LAMP SWITCH ON SIGNAL
POWERTRAIN CONTROL MODULE (PCM) (IN AIR CLEANER HOUSING)
PPL
PPL CLASS 2 SERIAL DATA
PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
RADIO
RIGHT TURN
TAN WIRE
W/AUTOMATIC AIR CONDITIONING
W/MANUAL AIR CONDITIONING
WHT WIRE
Go to component -> Warning systems circuit -> 1807 1807 PPL PPL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
