Buick LeSabre VII (1992-1999) turn/ hazard switch assembly Wiring diagram
This page shows the only wiring diagram for the component.turn/ hazard switch assembly, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn/ hazard switch assembly (1 of 1)
ANTI-LOCK BRAKE SYSTEM
BACK-UP LIGHTS
BLK WIRE
BRK/HZRD LPS FUSE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
CENTER I/P CROSS- CHANNEL)
CRUISE/SHIFT INTERLOCK/ BRAKE SWITCH
DK BLU WIRE
DK GRN WIRE
GRN WIRE
HAZARD FLASHER (BEHIND I/P, RIGHT OF STEERING COLUMN SUPPORT)
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P CROSS CHANNEL)
I/P FUSE BLOCK
INSTRUMENT CLUSTER
LAMPS W/O CORNERING
LEFT CORNERING LAMP
LEFT REAR SIDE MARKER LAMP LEFT LICENSE LAMP
LEFT STOP/ TURN/ PARK LAMP
LEFT TAIL- LAMPS
LEFT TURN INDICATOR
LEFT TURN SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER AIRBAG MODULE)
PERIMETER LIGHTING CONTROL RELAY (RIGHT SIDE OF DASH)
PERIMETER LIGHTING FUSE
PNK WIRE
PPL
RETAINED ACCESSORY POWER MODULE
RIGHT CORNERING LAMP
RIGHT LICENSE LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT STOP/ TURN/ PARK LAMP
RIGHT TAIL- LAMPS
RIGHT TURN INDICATOR
RIGHT TURN SWITCH
SIG/B-U/ LPS/BTSI/COR FUSE
TAN WIRE
TURN FLASHER (ATTACHED TO SOUND INSULATOR)
TURN/ HAZARD SWITCH ASSEMBLY
W/ CORNERING LAMPS
W/O CORNERING LAMPS
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> TURN/ HAZARD SWITCH ASSEMBLY
