Buick LeSabre VII (1992-1999) steering wheel control switch Wiring diagram
This page shows the only wiring diagram for the component.steering wheel control switch, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel control switch (1 of 1)
145 8 INTERIOR LIGHTS SYSTEM
6 SPEAKER SYSTEM
ANT ANT ENABLE REAR DEFOGGER
ANTENNA
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DK BLU WIRE
DK GRN WIRE
DK PPL
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, ACC OR W/ RETAINED ACCESSORY POWER
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH, ON DASH PANEL SOUND INSULATOR)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT FRONT DOOR SPEAKER
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LF CHNL OUT (+) LF CHNL OUT (-) RR CHNL OUT (-)
LT BLU WIRE
LT GRN WIRE
MISC/ RDO/CLSTR
NCA WIRE
ORG/ WIRE
PPL
PPL/WHT WIRE
RADIO
RADIO ANTENNA MODULE (LEFT REAR OF PASSENGER COMPARTMENT) AM ANTENNA FM ANTENNA
RADIO ANTENNA MODULE COIL
REAR DEFOGGER/ ANTENNA GRID
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RR CHNL OUT (+)
SERIAL DATA (UART)
STEERING COLUMN FUSE HOLDER SWITCH FUSE
STEERING WHEEL CONTROL SWITCH
TAN WIRE
TWEETER
VF DIMMING STRG WHL CTLR STRG WHL CTLR
WHT WIRE
WOOFER
YEL WIRE
Go to component -> Radio circuits -> STEERING WHEEL CONTROL SWITCH
