Buick LeSabre VII (1992-1999) right i/p power distribution center pcm fuse 8 Wiring diagrams

ANTI/LOCK INDICATOR BAT SOLID STATE BLK/WHT WIRE BRN/WHT WIRE DK BLU WIRE FROM ABS/TCS UART DATA LINE FROM PCM UART DATA LINE HOT IN RUN, BULB TEST OR START INSTRUMENT CLUSTER INSTRUMENT CLUSTER (PONTIAC) INFORMATION CENTER (BUICK) LT GRN/BLK WIRE OLDS OLDSMOBILE PCM FUSE 8 PNK WIRE PONTIAC PONTIAC ONLY RIGHT I/P POWER DISTRIBUTION CENTER RIGHT I/P POWER DISTRIBUTION CENTER PCM FUSE 8 TRACTION ACTIVE INDICATOR TRACTION CONTROL SWITCH TRACTION OFF INDICATOR

AIR BAG IND ANTI-LOCK BRAKES SYSTEM CRUISE CONTROL SYSTEM ANTILOCK IND BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (RIGHT SIDE OF I/P) BRAKE FLUID LEVEL SWITCH (MASTER CYLINDER RESERVOIR) BRAKE IND BRAKE WARNING INPUT BRN WIRE BRN/WHT WIRE COOLANT HOT IND. CTRL CRUISE IND DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROLS SYSTEM ANTI-THEFT SYSTEM ENGINE COOLANT TEMP IND ENGINE OIL PRESSURE SWITCH (BEHIND CAMSHAFT SENSOR) FASTEN BELTS IND. FUEL GAUGE FUEL GAUGE SENDER FUEL LEVEL IND CTRL FUEL LEVEL SENS INPUT FUEL TANK UNIT (TOP OF FUEL TANK) GRY WIRE HEADLIGHTS SYSTEM HI-BEAM IND HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (LEFT SIDE OF I/P) IGNITION SWITCH ACCY BULB TEST LOCK OFF INSTRUMENT CLUSTER INSTRUMENT PANEL ILLUMINATION LAMPS LEFT TURN IND LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION IND. LAMP (MIL) (SERVICE ENGINE SOON IND) MISC/RDO/ CLSTR NCA WIRE NORMAL OIL PRESSURE IND ORG/ WIRE PARK BRAKE SWITCH (TOP OF PARK BRAKE ASSEMBLY) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) PPL PPL/WHT WIRE RIGHT I/P POWER DISTRIBUTION CENTER PCM FUSE 8 RIGHT TURN IND RUN WIRE SECURITY IND SENSOR GROUND SPEEDOMETER (SOLID STATE) STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TOTAL ODOMETER TRIP ODOMETER VEHICLE SPEED SENSOR (LOWER RIGHT REAR OF ENGINE NEAR OIL PRES. SENSOR) VOLTS IND VSS INPUT VEHICLE SPEED OUTPUT 4000 P/M WARNING SYSTEMS WHT WIRE YEL WIRE
