Buick LeSabre VII (1992-1999) right i/p power distri- bution center Wiring diagram
This page shows the only wiring diagram for the component.right i/p power distri- bution center, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right i/p power distri- bution center (1 of 1)
4000 PULSES/MILE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE APPLIED INPUT CRUISE INHIBIT INPUT CRUISE STATUS VEHICLE SPEED INPUT
BRN WIRE
CRUISE CONTROL MODULE
CRUISE INDICATOR (BUICK)
CRUISE INHIBIT
CRUISE STATUS
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FUSE
FUSE FUSE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START
HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK FUSE 8
INSTRUMENT CLUSTER OR INFORMATION CENTER
LEFT FRONT FENDER)
LT BLU WIRE
MULTIFUNCTION LEVER
OFF
OFF ON
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT FRONT OF ENGINE COMPT)
PPL
PPL VSS RETURN
R/A
R/A CRUISE SWITCH
RIGHT I/P POWER DISTRI- BUTION CENTER
SET SW
STOP/BTSI/CRUISE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
TCC BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
VEHICLE SPEED SENSOR (VSS) (RIGHT REAR OF ENGINE)
VSS SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> RIGHT I/P POWER DISTRI- BUTION CENTER
