Buick LeSabre VII (1992-1999) rac/trunk rel fuse 2 Wiring diagram
This page shows the only wiring diagram for the component.rac/trunk rel fuse 2, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rac/trunk rel fuse 2 (1 of 1)
BLK WIRE
BLK/WHT WIRE
BUICK, OLDSMOBILE PONTIAC
ENGINE CON- TROLS SYSTEM
FROM LEFT FRONT STRUT)
HOT AT ALL TIMES
LT BLU WIRE
OLDS, BUICK
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (TOP LEFT SIDE OF TRANSAXLE)
RAC/TRUNK REL FUSE 2
REMOTE FUNCTION ACTUATOR MODULE (RIGHT SIDE OF DASH)
RIGHT I/P POWER DISTRIBUTION CENTER (BEHIND RIGHT SIDE OF I/P)
TRUNK LID RELEASE ACTUATOR (CENTER REAR OF TRUNK LID, NEAR LATCH)
TRUNK LID RELEASE RELAY (RIGHT I/P POWER DIST CTR)
TRUNK LID RELEASE SWITCH
VALET SWITCH
W/ RKE
