Buick LeSabre VII (1992-1999) pk lp/ int lps fuse Wiring diagram
This page shows the only wiring diagram for the component.pk lp/ int lps fuse, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pk lp/ int lps fuse (1 of 1)
242 256 240 PPL
BATTERY PK LPS CTRL BATTERY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CLUSTER CONNECTORS)
DK BLU WIRE
DK GRN WIRE
GRY/BLK WIRE
HEAD- LAMP SWITCH
HEAD/PARK LAMP SWITCH
HEADLAMP CIRCUIT BREAKER
HOT AT ALL TIMES
I/P FUSE BLOCK
LAMP CONTROL MODULE (BEHIND CENTER OF DASH, ABOVE HVAC CASE)
LEFT FRONT PARK/ TURN LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT UNDER- HOOD FUSE BLOCK
LT BLU WIRE
ORG/ WIRE
PARK LAMP SWITCH
PK LP FUSE
PK LP/ INT LPS FUSE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT PARK/ TURN LAMP
RIGHT FRONT SIDE MARKER LAMP
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> PK LP/ INT LPS FUSE
