Buick LeSabre VII (1992-1999) left seat switch Wiring diagram
This page shows the only wiring diagram for the component.left seat switch, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left seat switch (1 of 1)
ABS MOTOR FUSE
ABS SOLENOID FUSE
BATTERY
BLK WIRE
BUICK TO IGNITION SWITCH (DIAGRAM 4 OF 6)
C/LTR/RDO/ CLSTR/MISC FUSE
CIGAR LTR
CONSOLE CIGAR LIGHTER (PONTIAC W/ CENTER CONSOLE)
COOLFNS FUSE
ELC COMPRESSOR ASSEMBLY ELC RELAY
ELECTRONIC BRAKE, TRACTION CONTROL MODULE
FROM LEFT MAXI-FUSE BLOCK (DIAGRAM 1 OF 6)
FRONT CIGAR LIGHTER
GENERATOR
HDLP/LCM CIRCUIT BREAKER
HEAD PARK LAMP SWITCH
HEADLAMP DIMMER SWITCH
HEADLAMP RELAY
HEATER, A/C CONTROL ASSEMBLY
HIGH SPEED CONTROL FAN
I/P FUSE BLOCK
IGN SW FUSE
INFLATOR ELC HEIGHT SENSOR TIMER RELAY
LAMP CONTROL MODULE
LEFT LUMBAR SEAT RIGHT SEAT SWITCH LEFT SEAT SWITCH RIGHT LUMBAR SEAT
LEFT MAXI FUSE BLOCK
LEFT SEAT SWITCH
LOW SPEED CONTROL FAN
MEMORY SEATS/ MEMORY MIRRORS CONTROL MODULE (OLDSMOBILE)
MISC LGT FUSE
NCA WIRE
OLDSMOBILE
OLDSMOBILE BUICK PONTIAC
OLDSMOBILE BUICK PONTIAC OLDSMOBILE BUICK PONTIAC
ORG/ WIRE
PNEUMATIC SEAT CONTROL MODULE (PONTIAC)
PONTIAC W/ MANUAL CONTROL A/C W/ ELECTRONIC CONTROL A/C
PWR STS CIRCUIT BREAKER 3
REAR DEFOGGER RELAY
RED WIRE
RIGHT I/P POWER DISTRIBUTION CENTER
RIGHT I/P POWER DISTRIBUTION CENTER (OLDSMOBILE)
RIGHT MAXI- FUSE BLOCK TO IGN SW ACCY FUSE (DIAGRAM 2 OF 6) ELC FUSE
RR DEF/ SEATS FUSE
RR DEFOG
SEAT CONTROL MODULE (PONTIAC)
STARTER SOLENOID
TO I/P FUSE BLOCK (DIAGRAM 2 OF 6)
TO RDO, CLSTR
TO RIGHT MAXI FUSE BLOCK (DIAGRAM 1 OF 6)
W/ LEFT POWER SEAT W/ DUAL POWER SEATS
Go to component -> Power distribution circuit (1 of 6) -> LEFT SEAT SWITCH
