Buick LeSabre VII (1992-1999) i/p cross channel) Wiring diagrams
This page contains all the electrical diagrams for the component. i/p cross channel), in which he is found in the car Buick LeSabre VII (1992-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram i/p cross channel) (1 of 3)
16 39 (BUICK, PONTIAC) PPL PNK WIRE
694 294 (W/ KEYLESS ENTRY) (W/O KEYLESS ENTRY)
781 195 780 (W/ KEYLESS ENTRY) (W/O KEYLESS ENTRY)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (MALL) (BEHIND RIGHT SIDE OF I/P, ON MULTI-USE BRACKET)
CHIME
CTSY PWR MIR
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DOOR LOCK CONTROL
DOOR LOCK REQUEST INPUT DOOR LOCK REQUEST INPUT DOOR LOCK REQUEST INPUT
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM
DOOR UNLOCK CONTROL DOOR UNLOCK CONTROL
DR LKS FUSE 1
ENGINE CONTROLS SYSTEM
FASTEN BELTS INDICATOR CONTROL
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P CROSS CHANNEL)
I/P FUSE BLOCK
INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
JUNCTION CONNECTOR
LAMPS ON CHIME INPUT PARK INPUT
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK POSITION INPUT
PARK/NEUTRAL POSITION SWITCH (TOP LEFT SIDE OF TRANSAXLE)
PNK WIRE
PONTIAC W/O KEYLESS ENTRY
RED/BLK WIRE
RIGHT I/P POWER DISTRIBUTION CENTER
SIG/BU/ LPS/LCM
TAN WIRE
TAN/WHT WIRE
TURN SIGNAL INPUT IGNITION
VSS INPUT
WARNING SYSTEM
WARNING SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Body computer circuits -> I/P CROSS CHANNEL)
Wiring diagram i/p cross channel) (2 of 3)
ANTI-LOCK BRAKE SYSTEM
BACK-UP LIGHTS
BLK WIRE
BRK/HZRD LPS FUSE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
CENTER I/P CROSS- CHANNEL)
CRUISE/SHIFT INTERLOCK/ BRAKE SWITCH
DK BLU WIRE
DK GRN WIRE
GRN WIRE
HAZARD FLASHER (BEHIND I/P, RIGHT OF STEERING COLUMN SUPPORT)
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P CROSS CHANNEL)
I/P FUSE BLOCK
INSTRUMENT CLUSTER
LAMPS W/O CORNERING
LEFT CORNERING LAMP
LEFT REAR SIDE MARKER LAMP LEFT LICENSE LAMP
LEFT STOP/ TURN/ PARK LAMP
LEFT TAIL- LAMPS
LEFT TURN INDICATOR
LEFT TURN SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER AIRBAG MODULE)
PERIMETER LIGHTING CONTROL RELAY (RIGHT SIDE OF DASH)
PERIMETER LIGHTING FUSE
PNK WIRE
PPL
RETAINED ACCESSORY POWER MODULE
RIGHT CORNERING LAMP
RIGHT LICENSE LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT STOP/ TURN/ PARK LAMP
RIGHT TAIL- LAMPS
RIGHT TURN INDICATOR
RIGHT TURN SWITCH
SIG/B-U/ LPS/BTSI/COR FUSE
TAN WIRE
TURN FLASHER (ATTACHED TO SOUND INSULATOR)
TURN/ HAZARD SWITCH ASSEMBLY
W/ CORNERING LAMPS
W/O CORNERING LAMPS
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> I/P CROSS CHANNEL)
Wiring diagram i/p cross channel) (3 of 3)
BATTERY
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
BLOWER CONTROL MODULE HVAC BLOWER MOTOR
DATA LINK CONNECTOR
ENGINE COOLANT LEVEL SWITCH
ENGINE OIL LEVEL SWITCH
ENGINE OIL PRESSURE SWITCH
FROM JUNCTION
FROM TRACTION CONTROL SWITCH (DIAGRAM 2 OF 6)
FUEL LEVEL MODULE
FUEL PUMP RELAY
HIGH SPEED BLOWER RELAY (PONTIAC, OLDS W/ MANUAL A/C, BUICK W/ ELECTRIC A/C)
I/P CLUSTER
I/P CLUSTER (OLDS)
I/P CROSS CHANNEL)
IGNITION CONTROL MODULE
MAP SENSOR (PONTIAC)
MASS AIR FLOW (MAF SENSOR)
OLDSMOBILE
PARK/ NEUTRAL POSITION SWITCH
PASS-KEY II DECODER MODULE
POWERTRAIN CONTROL MODULE
PRNDL ILLUM. LAMP (OLDS)
RIGHT CORNERING LAMP
RIGHT FRONT PARK/ TURN LIGHT
RIGHT HIGH BEAM HEADLAMP
RIGHT HIGH BEAM HEADLIGHT (OLDS AND PONTIAC)
RIGHT HORN
RIGHT LOW BEAM HEADLAMP
RIGHT LOW BEAM HEADLIGHT (OLDS AND PONTIAC)
SHIFT CONTROL INDIC LAMP
WHT/ BLK WIRE
Go to component -> Ground distribution circuit (1 of 6) -> I/P CROSS CHANNEL)
