Buick LeSabre VII (1992-1999) inflator switch Wiring diagram
This page shows the only wiring diagram for the component.inflator switch, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inflator switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
ELC COMPRESSOR ASSEMBLY
ELC COMPRESSOR ASSEMBLY REAR DEFOGGER
ELC HEIGHT SENSOR
ELC INFLATOR SOLENOID
ELC TIMER RELAY
FUEL LEVEL SENDER
HEATED SEAT CONTROL MODULE
HEATED SEAT SWITCH
INFLATOR SWITCH
LEFT FOG LAMP LEFT FRONT DOOR FLOOD LAMP (PONTIAC)
LEFT FRONT DOOR HANDLE SWITCH
LEFT FRONT DOOR LOCK CYLINDER SWITCH
LEFT FRONT DOOR LOCK CYLINDER TAMPER SWITCH
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT SEAT SWITCH
LEFT FRONT SIDE MARKER LAMP (PONTIAC)
LEFT FRONT WINDOW SWITCH
LEFT REAR DOOR JAMB SWITCH
LUGGAGE COMPART- MENT LID TAMPER SWITCH
LUMBAR SEAT (OLDS)
LUMBAR SEAT PUMP (PONTIAC)
MEMORY SEAT/ MEMORY MIRROR MODULE (OLDS)
NCA WIRE
OLDS, BUICK
OLDSMOBILE
OUTSIDE MIRROR CONTROL SWITCH
PONTIAC W/ ACCESSORY INFLATOR
RIGHT FRONT DOOR HANDLE SWITCH
RIGHT FRONT DOOR KEY TAMPER SWITCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT SEAT SWITCH (PONTIAC)
RIGHT REAR DOOR JAMB SWITCH RIGHT FRONT DOOR LOCK SWITCH
SEAT ADJUSTER MOTOR (PONTIAC)
W/ AUTO LEVEL CONTROL W/O AUTO LEVEL CONTROL
Go to component -> Ground distribution circuit (5 of 6) -> INFLATOR SWITCH
