Buick LeSabre VII (1992-1999) door unlock input/output Wiring diagram
This page shows the only wiring diagram for the component.door unlock input/output, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door unlock input/output (1 of 1)
1995 VFTC
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
DATA LINE
DATA LINK CONNECTOR (BEHIND I/P, RIGHT OF STEERING COLUMN)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DOOR LOCK INPUT
DOOR UNLOCK INPUT
DOOR UNLOCK INPUT/OUTPUT
EXTERIOR LAMP INPUT
GROUND
HEADLAMPS ALARM OUTPUT
HORN RELAY CONTROL
HORNS SYSTEM (HORN RELAY)
HOT AT ALL TIMES TRUNK/REL/PWR ANT/RAC LKS FUSE 2
INDICATOR CONTROL
KEY UNLOCK INPUT
LAMP CONTROL MODULE (CENTER OF I/P)
LEFT FRONT DOOR LATCH SWITCH
LEFT FRONT DOOR LOCK CYLINDER SWITCH
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT DOOR OPEN IN
LEFT REAR DOOR LATCH SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
MULTI-FUNCTION ALARM, LOCK AND LIGHTING MODULE (BEHIND RIGHT SIDE OF I/P)
ORG/ WIRE
ORG/BLK WIRE
PASSENGER DOOR JAMB
PASSKEY CIRCUIT
PPL
RED/BLK WIRE
RELAY CENTER (RIGHT KICK PANEL)
REMOTE FUNCTION ACTUATOR MODULE (BEHIND RIGHT SIDE OF I/P)
RIGHT FRONT DOOR LATCH SWITCH
RIGHT FRONT DOOR LOCK CYLINDER SWITCH TAMPER SWITCH (BUICK) UNLOCK SWITCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT REAR DOOR LATCH ASSEMBLY
TAMPER SWITCH (BUICK) UNLOCK SWITCH
TAMPER SWITCH INPUT
TRUNK LID TAMPER SWITCH (NEAR LATCH)
UNLOCK
Go to component -> Forced entry circuit -> DOOR UNLOCK INPUT/OUTPUT
