Buick LeSabre VII (1992-1999) door lock input Wiring diagrams

1995 VFTC BLK WIRE CONNECTOR BREAKOUT) CROSS CHANNEL) CTSY PWR MIR DOOR LOCK INPUT DOOR LOCK OUT DOOR UNLOCK INPUT DOOR UNLOCK OUT GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK IGN/CHIME CLSTR JUNCTION LCM CONNECTOR BREAKOUT) LEFT FRONT DOOR LOCK LEFT FRONT DOOR LOCK MOTOR LEFT REAR DOOR LOCK MOTOR LOCK LT GRN WIRE MULTI-FUNCTION ALARM, LOCK, LIGHTING MODULE (MALL) (BEHIND RIGHT SIDE OF DASH) ORG/ WIRE ORG/BLK WIRE PARK POSITION INPUT PARK/ NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSAXLE) PNK BAT WIRE PNK WIRE RED WIRE RED/BLK WIRE RIGHT FRONT DOOR LOCK MOTOR RIGHT FRONT DOOR LOCK SWITCH RIGHT I/P POWER DISTRIBUTION CENTER (RIGHT SIDE OF DASH) DOOR LOCKS FUSE 1 RIGHT REAR DOOR LOCK MOTOR SIG/BU/LP BTSI/CCR SOLID STATE SWITCH UNLOCK LOCK TAN WIRE UNLOCK

1995 VFTC BATTERY BLK WIRE BLK/WHT WIRE BLU WIRE DATA LINE DATA LINK CONNECTOR (BEHIND I/P, RIGHT OF STEERING COLUMN) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DOOR LOCK INPUT DOOR UNLOCK INPUT DOOR UNLOCK INPUT/OUTPUT EXTERIOR LAMP INPUT GROUND HEADLAMPS ALARM OUTPUT HORN RELAY CONTROL HORNS SYSTEM (HORN RELAY) HOT AT ALL TIMES TRUNK/REL/PWR ANT/RAC LKS FUSE 2 INDICATOR CONTROL KEY UNLOCK INPUT LAMP CONTROL MODULE (CENTER OF I/P) LEFT FRONT DOOR LATCH SWITCH LEFT FRONT DOOR LOCK CYLINDER SWITCH LEFT FRONT DOOR LOCK SWITCH LEFT FRONT DOOR OPEN IN LEFT REAR DOOR LATCH SWITCH LOCK LT BLU WIRE LT GRN WIRE MULTI-FUNCTION ALARM, LOCK AND LIGHTING MODULE (BEHIND RIGHT SIDE OF I/P) ORG/ WIRE ORG/BLK WIRE PASSENGER DOOR JAMB PASSKEY CIRCUIT PPL RED/BLK WIRE RELAY CENTER (RIGHT KICK PANEL) REMOTE FUNCTION ACTUATOR MODULE (BEHIND RIGHT SIDE OF I/P) RIGHT FRONT DOOR LATCH SWITCH RIGHT FRONT DOOR LOCK CYLINDER SWITCH TAMPER SWITCH (BUICK) UNLOCK SWITCH RIGHT FRONT DOOR LOCK SWITCH RIGHT REAR DOOR LATCH ASSEMBLY TAMPER SWITCH (BUICK) UNLOCK SWITCH TAMPER SWITCH INPUT TRUNK LID TAMPER SWITCH (NEAR LATCH) UNLOCK
