Buick LeSabre VII (1992-1999) coolant temp ind Wiring diagram
This page shows the only wiring diagram for the component.coolant temp ind, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant temp ind (1 of 1)
* W/ TRACTION CONTROL ONLY
AIR BAG IND
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM STARTING/CHARGING SYSTEM
ANTILOCK IND
BLK WIRE
BODY CONTROL MODULE (RIGHT SIDE OF I/P)
BRAKE FLUID LEVEL SWITCH (MASTER CYLINDER RESERVOIR)
BRAKE IND
BRAKE WARNING INPUT
BRN WIRE
BRN/WHT WIRE
BULB TEST
CHANGE OIL IND.
CHANGE OIL SOON IND
CHECK OIL LEVEL IND
CHIME
COOLANT TEMP IND
CRUISE CONTROL SYSTEMS
CRUISE IND
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROLS SYSTEM
FASTEN BELTS IND.
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (LEFT SIDE OF I/P)
IGNITION SWITCH ACCY
INFORMATION CENTER
LOCK OFF
LT GRN/BLK WIRE
LT GRN/BLU WIRE
MALFUNCTION IND. LAMP (MIL) (SERVICE ENGINE SOON IND)
MSC/RDO/ CLUSTER
NCA WIRE
NORMAL
OIL LEVEL IND
ORG/ WIRE
PARK BRAKE SWITCH (TOP OF PARK BRAKE ASSEMBLY)
PNK WIRE
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
RUN WIRE
SECURITY IND
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN/WHT WIRE
TEMP IND
TRACTION OFF IND
VOLT IND
WARNING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Driver information center circuit, gauges cluster, ub3 -> COOLANT TEMP IND
