Buick LeSabre VII (1992-1999) at right side i/p, pont.-i/p harn., Wiring diagram
This page shows the only wiring diagram for the component.at right side i/p, pont.-i/p harn.,, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram at right side i/p, pont.-i/p harn., (1 of 1)
15 30 UART DATA UART DATA
15 59 UART DATA DATA CLSS 2 PPL
AT RIGHT SIDE I/P, PONT.-I/P HARN.,
BLK WIRE
BLK/WHT WIRE
BUICK, OLDS W/ DUAL ZONE A/C
COMPUTER COMMAND RIDE CONTROLLER (UNDER DRIVER'S SEAT)
DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P, RIGHT OF STEERING COLUMN)
DIAG OUT DIAG ENABLE
DK GRN WIRE
E&C SERIAL
ELECTRONIC BRAKE (AND TRACTION) CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HEATER AND A/C CONTROL ASSEMBLY (PONT. W/ AUTO A/C)
HOT AT ALL TIMES
HVAC PROGRAMMER (BUICK DUAL ZONE A/C) (BEHIND RIGHT I/P)
HVAC PROGRAMMER (OLDS DUAL ZONE A/C) (BEHIND RIGHT I/P)
HVAC PROGRAMMER (PONT. AUTO A/C) (BEHIND RIGHT I/P)
HVAC PROGRAMMER (W/ AUTO OR DUAL ZONE A/C) (RIGHT SIDE OF I/P)
I/P FUSE BLOCK
INSTRUMENT CLUSTER (OLDS EXCEPT DUAL ZONE)
LT BLU WIRE
LT GRN WIRE
OR AUTO A/C W/O DUAL ZONE
ORG/ WIRE
PONT. AUTO A/C
PONTIAC OTHERS
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
PPL
PROG ENABLE DATA CLSS 2 PPL
RADIO
RDO, CLSTR, MISC FUSE
REMOTE FUNCTION ACTUATOR MODULE (BEHIND RIGHT I/P, NEXT TO FUSE/RELAY BOX)
SENSING AND DIAGNOSTIC MODULE (SDM) (BELOW RIGHT FRONT SEAT, UNDER CARPET)
TAN WIRE
TRANSAXLE CONTROL INDICATOR DECODER MODULE (CENTER CONSOLE)
UART DATA
UART DATA UART DATA
W/ DUAL ZONE OR AUTO A/C
