Buick LeSabre VII (1992-1999) antenna output coaxial cable Wiring diagram
This page shows the only wiring diagram for the component.antenna output coaxial cable, which is found in the car Buick LeSabre VII (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram antenna output coaxial cable (1 of 1)
ANTENNA
ANTENNA OUTPUT COAXIAL CABLE
B+ DOWN MODE B+ DOWN MODE
B+ UP MODE GROUND DOWN MODE B+ UP MODE GROUND DOWN MODE
BLK WIRE
DK GRN WIRE
GROUND
GROUND UP MODE GROUND UP MODE
GRY WIRE
HOT AT ALL TIMES RAC/ TRUNK REL FUSE 2
HOT IN ACCY, RUN, W/ RAP ENERGIZED
I/P FUSE BLOCK
ORG/ WIRE
POWER ANTENNA MOTOR (RIGHT FRONT OF LUGGAGE COMPARTMENT)
RADIO
RIGHT I/P POWER DISTRIBUTION CENTER
TO RADIO
WHT WIRE
YEL WIRE
Go to component -> Power antenna circuit -> ANTENNA OUTPUT COAXIAL CABLE
