Buick LaCrosse III (2016-2019) rr stop/turn lp ctrl Wiring diagram
This page shows the only wiring diagram for the component.rr stop/turn lp ctrl, which is found in the car Buick LaCrosse III (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr stop/turn lp ctrl (1 of 1)
AUTO OFF
BATT POS VOLT
BLK WIRE
BLK/BRN WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRK APPLY SENS CTRL
BRK APPLY SENS SIG
BRL APPLY SENS LO REF
BRN/DK GRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DRV OUTSIDE REAR VIEW MIRROR PUDDLE LP CTRL
FUSE 18
FUSE 21
FUSE 22
FUSE 8
GRN/VIO WIRE
GRN/YEL WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HAZ LED DIMMING SIG HI SPD GMLAN SER DATA (-) 1
HAZ SW LEFT TURN SIG
HAZ SW RIGHT TURN SIG
HAZ SW SIG
HEAD PARK
HEADLAMP SW PARK LP SIG
HEADLAMP SWITCH
HI SPD GMLAN SER DATA (+) 1
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT CORNERING LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT PARK DAYTIME RUNNING LAMP
LF TURN SIG LP CTRL
LH CORNERING LP RLY CTRL
LH PARK LP CTRL
LR STOP LP CTRL
LR STOP/TURN LP CTRL
LT GRN WIRE
NCA WIRE
REAR LICENSE LP CTRL
RED/BRN WIRE
RED/DK BLU WIRE
RED/DK GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RF TURN SIG LP CTRL
RH CORNERING LP RLY CTRL
RH PARK LP CTRL
RR STOP LP CTRL
RR STOP/TURN LP CTRL
STOP LP RLY COIL CTRL
TURN SIGNAL/ MULTI-FUNCTION SWITCH
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ HID
W/O HID
WHT WIRE
WHT/YEL WIRE
YEL/DK BLU WIRE
YEL/GRY WIRE
Go to component -> Exterior lamps circuit (1 of 4) -> RR STOP/TURN LP CTRL
