Buick LaCrosse III (2016-2019) right cornering lamp rly ctrl Wiring diagram

ACCESSORY WAKEUP SERIAL DATA BACKUP LAMP CTRL BATTERY BATTERY CURRENT SENSOR BATTERY FUSE BLOCK BATTERY POSITIVE VOLTAGE BLK WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/WHT WIRE BODY CONTROL MODULE (UNDER FLOOR CONSOLE) BRN WIRE BRN/DK GRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COURTESY LAMP SW SIG CRUISE CONTROL SYSTEM CURRENT SENS CTRL CURRENT SENS LOW REF CURRENT SENS SIG DK BLU WIRE DK BLU/VIO WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/BRN WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE DOME LAMP OFF INDICATOR CTRL DOOR LOCKS, ANTI-THEFT SYSTEMS DR LCK ACTUATOR UNLOCK CTRL DR LOCK ACTUATOR LOCK CTRL DR LOCK ACTUATOR LOCK CTRL 2 DRV DR LOCK SW LOCK SIG DRV DR LOCK SW UNLOCK SIG DRV OUTSIDE REAR VIEW MIRR PUDDLE LAMP CTRL FOG LAMP RLY CTRL LIFT GLASS/REAR COMPT LID FUSE 4 GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE HDLP HIGH BEAM RLY CTRL HEADLAMP LOW BEAM RLY CTRL HEADLIGHTS SYSTEM HI SPD GMLAN SERIAL DATA (-) (1) HI SPEED GMLAN DATA BUS (-) HOOD STATUS B SIG HORN RLY CTRL HORNS SYSTEM HOT AT ALL TIMES INADVERTENT POWER CTRL INTERIOR LAMP CTRL INTERIOR LAMP DEFEAT SW SIG PPL LOGISTIC MODE RLY OPEN CTRL LED AMBIENT LIGHTING CTRL 1 LED BACKLIGHT DIMMING CTR LEFT CORNERING LAMP RLY CTRL LEFT PARK LAMP CTRL LEFT REAR DR LOCK MTR STATUS LEFT REAR STOP LAMP CTRL LF TURN SIG LAMP CTRL LIFT GLASS/REAR COMPT LID INTERIOR RELEASE SIG LIFTGATE AJAR SWITCH SIG 1 LINEAR INTERCONNECT NETWORK BUS 2 LINEAR INTERCONNECT NETWORK BUS 3 LOGISTIC MODE RLY CLOSE CTRL LR STOP/TURN SIG LAMP CTRL MTR RELEASE CTRL CRUISE/ETC/TCC BRAKE SIGNAL PASS DR LOCK SW LOCK CTRL PASS DR LOCK SW UNLOCK CTRL POWER DISTRIBUTION SYSTEM PUSH BUTTON START CHALLENGE ACTIVE REAR COMPT LID LAMP CTRL REAR LICENSE LAMP CTRL RED/GRY WIRE RED/WHT WIRE REMOTE PRNDL ENABLE RIGHT CORNERING LAMP RLY CTRL RIGHT FRT DRL CTRL RIGHT FRT TURN SIG LAMP CTRL RIGHT PARK LAMP CTRL RIGHT REAR DR LOCK MTR STATUS RIGHT REAR STOP LAMP CTRL RIGHT REAR STOP/TURN LAMP CTRL RR CLOSURE HANDLE SW OPEN SIG LINEAR INTERCONNECT NETWORK DATA BUS 1 RUN/CRANK RELAY COIL CTRL SERIAL DATA COMM ENABLE STARTING/CHARGING SYSTEM STOP LAMP RELAY COIL CTRL TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS VIO WIRE VIO/DK BLU WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/DK BLU WIRE WHT/YEL WIRE WINDSHIELD WASHER RELAY CTRL WINDSHIELD WIPER MTR RLY COIL WIPER/WASHER SYSTEM YEL WIRE YEL/BLU WIRE YEL/DK BLU WIRE
