Buick LaCrosse III (2016-2019) pass heated back ntc low ref Wiring diagram
This page shows the only wiring diagram for the component.pass heated back ntc low ref, which is found in the car Buick LaCrosse III (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass heated back ntc low ref (1 of 1)
BATTERY POSITIVE VOLT
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACK SEAT HEATING ELEMENT
DRIVER CUSHION SEAT HEATING ELEMENT
DRV HEATED BACK NTC SIG
DRV HEATED SEAT ELEMENT SPLY CTRL
DRV HEATED SEAT NTC LOW REF
DRV HEATED SEAT NTC SIG
DRV SEAT HEADREST MOTOR FORWARD CTRL
DRV SEAT VENT MOTOR CTRL 1
FRONT SEAT HEATING CONTROL MODULE
FRT HEATED SEAT FUSE
GRN/BLU WIRE
GRN/VIO WIRE
GROUND
GRY/BLK WIRE
HOT AT ALL TIMES
LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 2
NCA WIRE
PASS HEATED BACK NTC LOW REF
PASS HEATED BACK NTC SIG
PASS HEATED SEAT ELEMENT RETURN
PASS HEATED SEAT ELEMENT VOLT
PASS HEATED SEAT NTC LOW REF
PASS HEATED SEAT NTC SIG
PASS SEAT VENT MOTOR CTRL 1
PASSENGER BACK SEAT HEATING ELEMENT
PASSENGER CUSHION SEAT HEATING ELEMENT
POWER DISTRIBUTION SYSTEM
RED/BLU WIRE
RED/VIO WIRE
UNDERHOOD FUSE BLOCK
VIO/WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Front heated seats circuit (1 of 2) -> PASS HEATED BACK NTC LOW REF
