Buick LaCrosse III (2016-2019) front object sensor control 2 Wiring diagram
This page shows the only wiring diagram for the component.front object sensor control 2, which is found in the car Buick LaCrosse III (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front object sensor control 2 (1 of 1)
ACTIVE SAFETY CONTROL MODULE
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/VIO WIRE
DRIVER INFORMATION CONTROL DISPLAY
FRONT OBJECT SENSOR CONTROL 2
FRONT VIEW CAMERA (TOP CENTER OF WINDSHIELD)
FUSE 40
GMLAN SERIAL DATA (-) 8
GMLAN SERIAL DATA - 1
GROUND
GRY WIRE
GRY/LT GRN WIRE
GRY/VIO WIRE
HI SPD GMLAN SERIAL DATA (+) 4
HI SPD GMLAN SERIAL DATA (-) 4 LANE DEPARTURE WARNING DISABLE SW SIG
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LANE DEPARTURE WARNING DISABLE SWITCH
LANE DEPARTURE WARNING IND
LANE DEPARTURE WARNING IND CTRL
LO SPD GMLAN SERIAL DATA 2
LOGIC INSTRUMENT CLUSTER
LONG RANGE RADAR SENSOR MODULE
LOW SPEED GMLAN
LT GRN WIRE
RED/DK GRN WIRE
WHT WIRE
Go to component -> Lane departure warning circuit, w/ brake prefill & intelligent brake assist -> FRONT OBJECT SENSOR CONTROL 2
