Buick LaCrosse III (2016-2019) duct left upper air temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.duct left upper air temperature sensor, which is found in the car Buick LaCrosse III (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram duct left upper air temperature sensor (1 of 1)
A/C EVAPORATOR TEMPERATURE SENSOR
AIR IONIZER
AIR IONIZER ELECTRODE
BLK WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DUCT LEFT LOWER AIR TEMPERATURE SENSOR
DUCT LEFT UPPER AIR TEMPERATURE SENSOR
DUCT RIGHT LOWER AIR TEMPERATURE SENSOR
DUCT RIGHT UPPER AIR TEMPERATURE SENSOR
GRID -
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/RED WIRE
HVAC CONTROL MODULE (BEHIND HVAC CONTROLS)
RED/WHT WIRE
RIGHT AIR TEMPERATURE DOOR ACTUATOR
SERIAL DATA
VIO/GRN WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Automatic a/c circuit (4 of 5) -> DUCT LEFT UPPER AIR TEMPERATURE SENSOR
